Mark Reading Sensor |
Read Head | Photo reflector |
Reading side | Single side(Standard) Double side(Option) |
|
Light source | Infra-Red Ray(Standard) Visible Red Ray(Option) |
|
Mark Implements | Penci(l Standard) Pencil + Pen(Option) |
|
Read head Channel | 1/6”(48 columns) 0.2”(40 columns) |
|
Mark Shapes | Rectangle, Ovals, and Circles | |
Image Reading Sensor |
Sensor | CIS(Contact Image Sensor) |
Width capacity | 237 ㎜ | |
Reading side | Double sides | |
Color * | Grey-scale, Color | |
Optical dpi * | Up to 300dpi | |
Light color | Red, Green, Blue(620, 530, 467nm) | |
Output file * | JPEG,BMP,TIFF,PING,GIF | |
Connect with PC(Interface) | USB(Ver.2.0) | |
RS-232C | ||
Compatible | SR-601/607, SR-2300, SR-3500 | |
Display | Panel | 40 characters(20 x 2 lines) |
Control Button | 5 buttons | |
Form Capacity |
ADF(Hopper)Up to | 500 sheets |
Capacity Exit Bin Up | to 500 sheets | |
Scanning | Form Width | 63.5~228.6 ㎜(2.5”~9”) |
Form Length | 110 ~355.6 ㎜(4.3”~14”) | |
Number of Rows | Up to 107 Rows | |
Mark Position | Up to 5,136 Mark Positions (48 columns) Up to 4,280 Mark Positions (40 columns) |
|
Throughput speeds |
OMR only : 3,500 sheets/h Color/Gray-scale(100dpi): 2,200sheet/h |
|
Thickness | OMR : 72~135kg(84 – 157g/m2) Image : 55~135kg(64 – 157g/m2) |
|
Power | Volt. / Relatives | AC100V~240V / 50~60Hz |
Conditions | Temp / Humid | 5~35℃ / 30~80% |
Dimensions | W×H×D(mm, Inch) | 365 x 227 x 575mm (14.4”x 9”x 22.6”) |
Weight | 18.3kg(40.3lb) | |
Accessories | CD-ROM(User Manual, USB Driver, API, Diagnostic utility software), Power cable(AC Adaptor), USB cable |
